This WYTG liquid adding equipment is used for adding oil, molasses, phospholipids and other liquids when mixing formula feed with batch mixers. It is suitable for adding trace elements, oils and other liquids to mixers in biochemical, food, feed and other industries.
This WYTG liquid-adding equipment is used for adding oil, molasses, phospholipids, and other liquids when mixing formula feed with batch mixers. It is suitable for adding trace elements, oils, and other liquids to mixers in biochemical, food, feed, and other industries. The working environment temperature is usually 0℃～ +40°C. This is an indispensable link in feed processing, which can improve feed quality and processing performance.
WYTG liquid-adding equipment is composed of the hot water tank, molasses tank, liquid distribution tank, sensor, high-precision solid metering system, high-precision liquid scale, pipeline system, PLC electronic control system, spraying device, etc. It can add 2-40 tons of various liquids at the same time, which can meet the needs of large, medium, and small feed mills, and can be customized.
Microcomputer automatic control, triple coverage, accuracy, and reliability. Liquid temperature and liquid level can automatically be controlled in the tank.
It adopts a load cell to measure, the accuracy can reach 0.5%.
Equipped with auxiliary booster device, eliminating stops spraying nozzle dripping oil, according to material agglomeration problems.
Equipped with coarse and fine filters in the oil inlet and outlet to filter out the impurities in the liquid and prevent the flow meter and nozzle from being blocked.
Equipped with various reliable electric pumps for a variety of liquids, with a good shaft seal.
Suitable for adding nutrients such as fat, molasses, and phospholipids to batch mixers.
| Model | Capacity | Power(kW) |
| WYTJ50 | 0-50kgs | 2.2 (Decrease scale) |
| WYTZ50 | 0-50kgs | 2.2+2.2(increase scale) |
