The wood biomass pellet mill can successfully compact organic products of various particle sizes, moisture contents, and bulk densities. The wood pellet maker is uniquely designed to pellet wood waste, shavings, chips, sawdust, and sanding dust.
The wood biomass pellet mill can successfully compact organic products of various particle sizes, moisture contents, and bulk densities. The wood pellet maker is uniquely designed to pellet wood waste, shavings, chips, sawdust, and sanding dust. It is widely used for recycling usage of waste and tailings in wood processing plants, biomass fuel plants, power plants, furniture factories, fertilizer plants, chemical factories, foodstuffs factories, and breweries.
1. Frequency conversion feeding can be used to effectively prevent uneven feeding caused by unstable voltage.
2. The main transmission adopts a high-precision gear transmission, and the ring die adopts a quick-release hoop type. The output is about 20% higher than that of the belt drive type.
3. A Force Feeder can allow light raw materials to enter the granulation chamber better so that the granulation process can proceed normally.
4. Safety With safety devices such as strong magnetic magnets and overload protection, it is safe and reliable.
5. The optimized structure of the pelletizing chamber ensures the uniform distribution of the pressing material and maximizes the working potential of the pelletizing machine.
6. The drive of the main engine adopts high-precision gear transmission, and the ring die adopts anchor type, which is convenient for disassembly and assembly.
| Model | MZLH320 | MZLH350 | MZLH420 | MZLH520 | MZLH768 | MZLH858 |
| Anti-caking Feeder Power(kw) | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 3 |
| Pellet Machine Power(kW) | 0.55 | 0.55 | 0.55 | 0.75 | 1 | 1 |
| Capacity(kg/h) | 300-400 | 500-700 | 1000-1200 | 2000-2500 | 2500-4000 | 3000-4500 |
| Pellet Machine Power(kW) | 37 | 55 | 90 | 110/132 | 250/280 | 280 |
| Final Pellet(mm) | 6-12 | 6-12 | 6-12 | 6-12 | 6-12 | 6-12 |
